| Attribute | Specification |
|---|---|
| model info | WS-C3850-24XS-E |
| enclosure type | Rack-mountable – 1U |
| Ports | 24 x SFP+ ports |
| Network management Interface | ● Ethernet management port: RJ-45 connectors, 4-pair Cat-5 UTP cabling● Management console port: RJ-45-to-DB9 cable for PC connections |
| Available PoE Power | None |
| Switching Capacity | 320Gbps |
| Maximum stacking number | up to 9 switches with same IOS feature set in same series |
| Stack Bandwidth | 480Gbps |
| Forwarding Performance | 454.55Mpps |
| FNF entries | 48,000 flows |
| Maximum VLANs IDs | 1,000 |
| MAC Address Table Size | 32K |
| CPU | Multicore CPU |
| RAM | 4 G |
| Flash Memory | 4 G |
| Wireless | |
| Number of AP per switch/stack | 100 |
| Number of wireless clients per switch/stack | 2000 |
| Total number of WLANs per switch | 64 |
| Wireless bandwidth per switch | up to 20Gbps |
| Supported Aironet AP series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Expansion / Connectivity | |
| Console ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slot(s) | 1 network module slot and 1 power redundant slot |
| Network Modules Selection | ● C3850-NM-4-1G: 4 x 1G uplinks network module● C3850-NM-2-10G: 2 x 10G or 4 x 1G uplinks network module |
| Stacking cable | ● STACK-T1-50CM StackWise stacking cable with a 0.5 m length● STACK-T1-1M StackWise stacking cable with a 1.0 m length● STACK-T1-3M StackWise stacking cable with a 3.0 m length |
| Stack Power Cable (recommended) | ● CAB-SPWR-30CM stack power cable with a 30CM length● CAB-SPWR-150CM stack power cable with a 150CM length |
| Power supply | PWR-C1-715WAC |
| Power Device | Power supply – redundant – plug-in module |
| Power Redundancy | optional |
| Voltage range (Auto) | 100V-240V |
| Power Consumption of standalone(in Watts) | 205.5 (Max) |
Cisco WS-C3850-24XS-E 24-Port 10G SFP+ Enterprise Switch
The Cisco WS-C3850-24XS-E is a 1U Catalyst 3850 switch with 24 SFP+ ports, Layer 3 IP Services, 320Gbps switching capacity and StackWise-480 stacking. Built for enterprise campus networks, it delivers scalable 10G connectivity, Flexible NetFlow visibility, redundant power, and resilient performance.
